| Main Parameters | |
| Projection Technology | 3LCD |
| Standard Resolution | WXGA/XGA/4K Enhancement |
| Light Source | Laser |
| Brightness (MKT) | 2000-2600lm |
| Throw Ratio | 1.46-1.76 |
| 1.35-1.63 | |
| 1.48-1.78 | |
| Lens Shift | N/A |
| Power Range | AC100~240V |
| Operating Altitude | Below 3000m |
| Operating Temperature | 0℃~40℃ |
| Dimensions(W * D * H)(mm) | 248*233*105.7mm（without adjustable foot height） 248*233*114.2mm（with adjustable foot height） |
| Net Weight(kg) | 2.8-3kg |
| Accessories | Power cable/Remote control/Batteries/HDMI cable |
| Interface Parameters | |
| VGA IN | NA |
| HDMI IN | *2 |
| USB-A | *1 |
| USB-B | NA |
| RJ45 | *1(Display) |
| HDBaseT | NA |
| Audio in | NA |
| VGA OUT | NA |
| Audio out | *1 |
| RS232 | NA |
| RJ45 | NA |
| Main Parameters | |
| Projection Technology: | 3LCD |
| Standard Resolution | 4K Enhancement |
| Light Source | Laser |
| Brightness (MKT) | 2000lm |
| Throw Ratio | 1.35-1.63 |
| Lens Shift | N/A |
| Power Range | AC100~240V |
| Operating Altitude | Below 3000m |
| Operating Temperature | 0℃~40℃ |
| Dimensions(W * D * H)(mm) | 248*233*169mm |
| Net Weight(kg) | 4.4kg |
| Accessories | Power cable/Remote control/Batteries/HDMI cable |
| Interface Parameters | |
| VGA IN | N/A |
| HDMI IN | *2 |
| USB-A | *2 |
| USB-B | N/A |
| RJ45 | *1(Display) |
| HDBaseT | N/A |
| Audio in | N/A |
| VGA OUT | N/A |
| Audio out | *1 |
| RS232 | N/A |
| RJ45 | N/A |
